23BWDBH
23BWDBH
Window Mount – Thermo Ventilator (Advance Type)
Window Mount Installation
Easy installation with small installation size
Maximum Power Consumption: 1,400W
Ventilation Speed up to 220m3/h
New RF IPX4 Remote Control with magnetic base
Ventilation / Heating / Dry Hot (Clothes Drying) / Dry Cool (Circulation) Feature
Auto/ Manual Swing Operation
Color: Pearl White
Price: HK$3,380
Other Models
23BWBH
► 23BWDBH
30BGCH
30BWBH/H
30BWBH/W
40BECH
40BLAH
Feature
Specifications
FAQ
Recipe
User Manual
Catalogue
Downloads:
Feature
Window Mount Installation
Duct Installation is not required
Maximum Power Consumption: 1,400W
Ventilation Speed up to 220m3/h
New RF IPX4 Remote Control with magnetic base(Need to pair with the product before use)
Smaller installation size with dimension of 242 x 238mm (H x W)
Louver Size (mm): 280 (H) x 280 (W)
Size(mm) : 280 (W) x 280 (H) x 286 (D)
Pre-set Timer Control Feature
Ventilation / Heating / Dry Hot (Clothes Drying) / Dry Cool (Circulation) Feature
Auto/ Manual Swing Operation
Antibacterial Filter
Max. Time
- Heat: 180 mins
- Vent. CONT.
- Dry Hot: 360 mins
- Dry Cool: CONT.
Specifications
23BWDBH
23BWDBH
Net Weight
4.7 Kg
Wattage
Ventilation
34 W
Max. Wattage
1,400 W
Air Volume
Ventilation
220 CMH
Noise Level
Ventilation
48 dB
Heating
48 dB
Heater
PTC
Control Type
Wireless Remote
Heating
Yes
Dry
Hot‧Cool
Ventilation
Yes
Timer
15/30/60/180/360 (Minute)
Filter
Antibacterial Filter
No. of Motor / Blade
1 / 1
No. of Exhaust Outlet
1
Installation Hole Size
238 x 242 mm
9.37 x 9.53 inch
(W x H)
FAQ
🙋 Installation hole size and louver size
Model
Type
Installation hole size Height x Width (mm)
Louver size Height x Width (mm)
23BWAH
Window Mount
242 x 238
280 x 280
23BWBH
Window Mount
242 x 238
280 x 280
23BWDBH
Window Mount
242 x 238
280 x 280
30BWBH
Window Mount
300 x 275
350 x 320
30BGCH
Ceiling Mount
300 x 300
360 x 360
40BECH
Ceiling Mount
280 x 400
350 x 472
40BLAH
Ceiling Mount
280 x 400
350 x 472
* The product is subject to the actual product. Photos and product shots are for reference only. The actual color and size may vary slightly from those shown.
* Product specifications are subject to change without prior notice.
